Protein Crystal Manipulation Projects

Motivation and Background

A large and ambitious effort, called the Protein Structure Initiative, is underway in the United States and similar efforts exist worldwide to determine the atomic-level 3-D structures of proteins. This is expected to have a significant impact on biological and medical research by shedding light on the relationships of structure to function and disease, directing structure-based drug design and refining our understanding of evolutionary relationships between proteins, among others.

HTP pipeline

Fig.1: High-throughput Crystallography Pipeline

Protein Crystals

Fig.2: Protein Crystals

The structure determination effort centers on developing the capability of processing proteins on a large scale --- a high-throughput pipeline starting with producing the proteins in large quantities and leading through various stages to the eventual determination of the spatial arrangement of the protein atoms. X-ray crystallography is one of the two most popular methods for structure determination; the other is NMR spectroscopy. A simplified version of the X-ray crystallography high-throughput pipeline is shown in the diagram to the right.

Protein crystals are usually incubated in a droplet, about 1-2 ul in volume, that is a mixture of protein and reagent which is necessary to cause nucleation. In the hanging drop method, the droplet is deposited onto a plastic coverslip which is then flipped over to seal the well in the plate where it is going to be incubated. There are many different types of crystallization plates with the number of wells varying depending on their intended use. One very popular type is the 24-well Linbro plate.

The aim of the Protein Structure Initiative is to acquire the structures of as many protein families as possible. The number of the different protein families is estimated to be around 40,000, of which a total of about 600 (as of 2004) are solved per year and deposited to the Protein Data Bank. This makes the task a gigantic undertaking and necessitates the development of strategies and tools for automated and fast manipulation of protein and protein crystals.

There has been a tremendous progress in high-throughput technology development for structural genomics projects in the past decade. Most of highest-demand tasks have been automated to one degree or another. However, there are quite a few tasks that are still performed manually and take valuable time and efforts from crystallographers and lab technicians.

We have identified and are addressing two such tasks: crystal mounting and streak seeding. Our work is aimed at using computer vision to provide the compliance and robustness with precise crystal manipulation requires without the need for extensive analysis of the physics of grasping or a detailed knowledge of the environment.
